This is a complete, ready-to-run solar setup. Everything you need to take your home or business off the grid, or at least off NEPA’s schedule.

The 3kVA hybrid SRNE-inverter handles both hybrid and non-hybrid configurations, transformer-based or not. It runs on pure sine wave output, so your sensitive appliances, refrigerators, TVs, laptops, medical equipment, all get clean, stable power. No humming. No voltage spikes.

The 5kWh Luxwatt LiFePO4 battery stores enough to keep you running comfortably through the night. At 80% depth of discharge, you’re getting 4kWh of real, usable capacity.

Then there are the panels. Six units at 550W each. That’s 3,300W of solar input. On a decent Lagos afternoon, this setup recharges your battery in a few hours and powers your home simultaneously. The MPPT charge controller on the inverter pulls maximum current even when clouds cut in, so you’re not losing half your generation to weather.

What this system can run:

Fans (multiple), LED lights throughout the house, a 1.5HP inverter AC, refrigerator or freezer, water pump, TV, laptops and phone chargers, microwave (intermittent use), small business equipment like printers, CCTV, and routers.

A typical 3-bedroom home runs comfortably on this. Small offices too.

What to keep in mind: Heavy-draw appliances like pressing irons and water heaters are outside this system’s range. The 3kVA inverter handles up to 2,400W of continuous load, so you’ll want to stagger your high-draw appliances rather than running them all at once.

System Specifications

Inverter

• Output Power: 3kVA / 3,000W
• Input Voltage: 24V DC
• Output: Pure Sine Wave, 220V AC
• Compatible: Hybrid and non-hybrid, transformer and non-transformer based
• Built-in MPPT Solar Charge Controller
• Protections: Overload, short circuit, over-voltage, under-voltage, over-temperature, reverse polarity

Battery

• Capacity: 5kWh
• Chemistry: LiFePO4 (Lithium Iron Phosphate)
• Voltage: 24V
• Depth of Discharge: 80%
• Cycle Life: 6,000+ cycles (up to 10,000)
• Lifespan: 10 to 15 years
• BMS: Built-in intelligent Battery Management System
• Maintenance-free

Solar Panels

• Configuration: 6 x 550W monocrystalline panels
• Total Solar Input: 3,300W
• Panel Voltage: Compatible with 24V system via MPPT controller
• Designed for maximum output in tropical/high-sunlight conditions

System Totals

• Total Solar Generation: 3.3kW peak
• Total Storage: 5kWh (4kWh usable at 80% DOD)
• System Voltage: 24V
• Inverter Capacity: 3kVA continuous
